FTTH Cable Production: Manufacturing Process Explained
Quick fact: in excess of seventy percent of new U.S. broadband builds now rely on fiber networks that require high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment runs complete fiber secondary coating line manufacturing, from choosing brand fibers like Fujikura or Corning® SMF-28e to comprehensive test documentation that ensure 100% quality assurance.
Our drop cable designs fit aerial, ducted, and direct burial installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and core counts from 1–4 cores. We offer OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone sheath colors, and logo printing.
Automated machines and high-precision equipment keep line speed steady and maximize repeatability. Typical lead times run 4–5 days for orders < 100 km and 7–10 days under 500 km, with an min. order of 1 km and warranty covering free replacement for confirmed quality issues.
Keep reading to see how materials, testing, and support combine to lower lifecycle cost and pair the right product with your network.
- Shanghai Weiye OFC Equipment offers full manufacturing with lab validation for U.S. deployments.
- A range of jacket options and optical grades cover indoor/outdoor environments.
- Automated production lines provide stable quality and stable optical performance.
- Fast lead times, low minimums, and brand fiber options support reliable procurement planning.
- Complete reports and after-sales warranty support product reliability and documentation needs.
Specialized FTTH Manufacturing by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment delivers customized drop cables with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines specialized equipment with stringent material control. We provide custom builds and services for residential/MDU deployments. Every order comes with 100% quality assurance and complete test reports.
Our lab conducts high-temperature, salt spray, and vibration tests to validate durability. Jacket options cover LSZH, PVC, and PE. Designs cover flat bow-type and self-supporting styles and support brand fibers such as Fujikura and Corning® SMF-28e.
- Documented line control and production checks for auditable shipments.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixtures and calibration minimize variation so every cable meets carrier standards.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, combining brand fiber choices with rigorous test routines.
Fiber Selection & Brand Options
We align FTTH cable production line to minimum bend radius, attenuation, and deployment type. Options include OS1/OS2 and OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura and Corning® SMF-28e are offered to satisfy sourcing standards.
Integrating Strength Members
Strength members employ FRP (dielectric) or metallic steel wire. FRP is preferred where non-conductivity is necessary. Steel wire provides tensile strength for longer aerial spans and grounding needs.
Extrusion & Process Control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for outdoor UV and moisture resistance. Tight process control of temperature and capstan ratios keeps line speed stable and dimensional tolerances.
| Component | FRP | Metallic Steel |
|---|---|---|
| Use case | Electrical isolation | Aerial spans, high tensile |
| Advantage | Light, non-corrosive | Very high tensile strength |
| Installation note | Easier terminations | Bonding/grounding required |
Inline and final testing
Inline geometry and concentricity checks run during manufacturing. Final optical tests confirm loss and return loss. Each order includes a full test report and lab results from high heat, salt-spray, and vibration tests to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a focused portfolio of drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It reduces bend loss for simple routing in MDU corridors and hallways.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs include a support messenger to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding/grounding and extra tensile strength are required.
Layouts & Strength Members
We offer dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and flat unitube types balance crush resistance and fiber secondary coating line for fast terminations.
Indoor/outdoor jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each family is qualified for mechanical/optical performance before shipment.
| Design | Best use | Strength element | Jacket |
|---|---|---|---|
| Bow-type flat | Indoor risers, MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Overhead spans | Steel wire or FRP | Polyethylene |
| Central loose-tube | Higher fiber counts | Dielectric FRP | LSZH or PE |
| Unitube flat | Low-count, easy strip | FRP or steel | LSZH/PE |
Production Assets for Speed and Quality
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut/strip drop cords to increase output and reduce operator variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP/steel members to precise stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and minimize downtime.
PLC/photoelectric control for precision and repeatability
PLC logic + photoelectric sensors give exact positioning and feedback control. Inline checks update SPC charts so operators can correct trends before defects grow.
| Feature | Spec | Benefit |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinders | High speed and reliability |
| Materials | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading keep the line clean.
- Process control plans document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without compromising accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize terminal quality. The unit runs at an approximate cycle time of 1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control deliver exact detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Cycle time and throughput
Typical operation speed is ~1.5 seconds per cycle. This converts to steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5 to 35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
FRP & Steel Member Handling
The machine cuts FRP/steel strength elements cleanly while protecting neighboring fibers. Customized cutters are available for non-standard cross-sections to maintain precision.
- Automatic waste ejection and sensor-triggered start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass ease integration into workcells.
- Pneumatic cylinders and closed-loop control improve line reliability and reduce maintenance downtime.
| Specification | Value | Benefit |
|---|---|---|
| Cycle | ≈1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5–35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0 to 11.0 mm | Meets strength and termination needs |
| Power & size | 110–220V, 50W; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures each build to fit your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1–4 core designs with SM or MM fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D and G.657 variants to align with optics and connector plans.
We Pantone-match sheath colors for fast field ID and consistent asset tagging.
Branding and Print Options
Select LSZH/PVC/PE jackets to suit route and safety requirements. Custom print legends and logos support inventory and warranty tracking.
Lengths, Packaging & Special Builds
Standard reel lengths are 1/2/4 km with tailored reels and packaging to fit storage/handling. Choose bow-type flat or self-supporting designs and steel wire or FRP strength members to fit span and isolation requirements.
| Choice | Typical | Advantage |
|---|---|---|
| Reel length | 1, 2, or 4 km | Simpler staging and reels |
| Jacket | LSZH / PE / PVC | Indoor/Outdoor fit |
| Design | Bow-type / Self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye schedules runs to your plan and delivers documentation that lists final specifications for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs elevated-temperature exposure, salt fog corrosion, and vibration tests to qualify materials/assemblies. These tests simulate field stresses for indoor/outdoor applications.
Per-Reel 100% Reports
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Audit Trail and Compliance
Lot/batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and lower warranty events.
- Quality packages include specifications confirmation and formatted data for rapid review.
- Ongoing trend analysis inform preventive maintenance and improve long-term reliability.
| Trial | Why | Outcome |
|---|---|---|
| Heat exposure | Thermal stability | Validated heat endurance |
| Salt spray | Corrosion robustness | Qualified for outdoor use |
| Vibration | Mechanical robustness | Improved field reliability |
Pricing and cost drivers for FTTH drop cable
Budgeting for a drop run starts with fiber and jacket choices and is refined by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade, jacket material, reel length, and structural design.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting structures and steel members raise material and labor input. Custom colors, logos, and print legends add setup time and influence price for short runs.
Order length, volume, and customization impact on price
Longer put-ups and larger volumes reduce unit cost. Short runs often carry setup fees and higher per-unit charges.
- Changeovers and special cutters increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Driver | Price impact | Recommendation |
|---|---|---|
| Fiber grade | Large | Balance spec vs. budget |
| Sheath material | Medium | Compare LSZH vs. PE for total cost |
| Order length / volume | High impact | Consolidate runs to cut unit cost |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable windows reduce downtime and control costs when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For compressed schedules, we hold contingency capacity to pull in critical-path orders.
Why MOQ Matters
The MOQ is 1 km. This reflects setup needs such as wire and jacket die adjustments that consume start-up material and scrap.
We review your length and staging plans to select reels to reduce waste/handling. Batch releases can balance inventory holding with frequent, smaller deliveries to job sites.
Installation readiness and application scenarios
Site conditions dictate whether a self-supporting span, duct pull, or direct burial is the right choice for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with correct strength members to manage sag/tension for long-term reliability.
Duct installations work best with low-friction jackets and crush-resistant constructs so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the optic core over time.
Indoor Distribution and ONT
Indoor riser/plenum routes prefer LSZH to meet flame and smoke rules. Flat drop cable forms strip cleanly and present controlled stubs for fast ONT terminations.
We advise on steel vs FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware compatibility. Standardized line prep shortens install time and reduces scrap.
| Deployment | Key feature | Installer note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Interior | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and reliable field performance for your system.
End-to-end support and after-sales service
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pre-production builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to help QA acceptance.
- 24/7 availability for status and technical support.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for urgent changes or acceleration requests.
- Configuration control so shipped items match agreed specs consistently.
| Area | Scope | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab trials & 100% test reports | Full traceability |
| Service | Fast replace + RCA | Lower downtime |
Conclusion
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We deliver customized FTTH drop solutions that pair material choices with validated manufacturing and lab testing. Every reel includes a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2-enabled prep machines, cuts variability and speeds turnaround. Our equipment and machines standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment stays on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with laboratory validation and responsive support.
